Pin Peripheral Selection This page lets you build an FPGA image containing up to nine peripherals of your choice. The enumerator and bb4io peripherals are included in every build.



Step 1: Peripheral Selection

Add a peripheral to your build by changing its count from the default value of zero. Unused slots are filled with the Quad General Purpose I/O peripheral.

User Interface

Audio amplifier with volume control and mute
Text LCD and keypad interface
Quad WS2812 RBG(W) LED interface
Quad slide potentiometer
Consumer IR receiver/transmitter
Six digit LCD display
6/8 channel RC decoder
Keyfob remote control
Rotary encoder with center button
Quad capacitive touch sensor

Motion Control

Dual DC motor controller
Dual quadrature decoder
Quad servo motor controller
Unipolar stepper motor controller
Bipolar stepper motor controller

Simple Input / Output

Quad binary output
Quad binary input
Quad bidirectional I/O
Octal input / output
32 Channel binary output
32 Channel binary input
Quad Serial Output
Octal Serial Output

Sensors

Octal 12-bit ADC
Quad Parallax PING))) interface
Octal SRF04 interface
Quad event counter
Quad Pololu QTR interface
Octal Pololu QTR interface

Instrumentation

SPI interface
I2C interface
Octal 8-bit DAC
Quad digital potentiometer
Quad PWM output
Quad PWM input
Real-time clock
Dual Pulse Generator

Controllers

AVR Microcontroller
Host Serial







FPGA Defined Peripherals
